Floor Pan Installation Guide

Last updated: February 1, 2026

Tools

  • 3/16 allen key
  • 1/2 wrench or socket

Hardware Required

  • 5/16-18 x 3/4" Button Head Bolt (8)
  • 5/16-18 Nylock Nut (8)

Installation Steps

  1. Mount the Floor Pan to the Floor Pan Tabs using the hardware

Additional Information

  • Frame Assembly
